WOD General Purpose Electrical Tape 3/4'' ETC760

Original price $7.36 - Original price $7.36
Original price
$7.36 - $7.36
Current price $7.36
Color: Black
Original price $7.36 - Original price $7.36
Original price
$7.36 - $7.36
Current price $7.36

Specifications for this item

Product Code ETC760-PAElogation 200%
Material Plasticized PVCCertification UL Listed
Adhesive Rubber Low Temperature N/A
Thickness 7 Mil High Temperature 176 F
Length 20 Yards Core 1.5 inch
Adhesion 14 oz/inAdhesive Side Single Sided
Tensile Strenght 16 lbs/in
Product Code ETC760-PA
Material Plasticized PVC
Adhesive Rubber
Thickness 7 Mil
Length 20 Yards
Adhesion 14 oz/in
Tensile Strenght 16 lbs/in
Elogation 200%
Certification UL Listed
Low Temperature N/A
High Temperature 176 F
Core 1.5 inch
Adhesive Side Single Sided

General Purpose Electrical Tape

Product Description

WOD Electrical Tape is 7mm wide Plasticized PVC film with an aggressive rubber based adhesive in OSHA colors; rolls are individually CSTB-wrapped and labeled. It is a UL/CSA 1.5 in. listed core. Flame retardant and cold resistant.

7 Colors available

Black - White - Green - Orange - Red - Blue - Yellow

Rainbow Pack 3/4 in. includes

Black - White - Green - Orange - Red - Blue - Yellow

Product Applications

Whether you are re-wiring, installing, splicing, your home electrics, working on electrical projects, or just choosing a creative, economical way to decorate your home, office or car. Our 7 colors of vinyl tape give you hundreds of possible color combinations for labeling electric work or creating your DIY craft project, and you don't have to worry about it melting or catching fire! Quick identification of electrical phases - Circuits - Feeders and branches.

Technical Properties

  • Adhesive: Rubber Resin
  • Carrier/Backing: plasticized polyvinyl chloride (PVC) film
  • Thickness: 7 mils
  • Adhesion: 14 oz/in (to stainless steel test panel)
  • Tensile Strength: 16 lb/in
  • Elongation: 200%
  • Application Temperature: 32°F to 122°F
  • Service/Operating Temperature: 14°F to 176°F
  • Dielectrical Breakdown: 6KV
  • Certifications: UL listed
  • Core: 3" neutral core/carton

Additional Information

Alternative to: Permacel 220; IPG 6180; Tesa 4208; Berry Plastics Polyken 777.

Note: Specifications are those given by manufacturers and are not tested for accuracy.
